Optrel does it again with the Optrel Helix CLT 1050.200 helmet. This helmet is ideal for you if you need the practical slide-up function to switch between different tasks, and also want a large field of view with extremely bright and true color vision when welding.

The new slide-up welding helmet with panoramic field of view and Crystal Lens Technology

With the helix CLT, optrel offers a welding helmet for work under the most difficult conditions. A slide-up helmet with internal ADF that has all the technical features of an optrel helmet:

  • Panorama XXL field of view,
  • ShadeTronic®,
  • Fadetronic,
  • rechargeable battery unit with charging via welding arc and
  • 5-point multi-detection sensor technology.

The helix clt is ideal for you if you need the convenient slide-up function to switch between different tasks, and also want a large field of view with extremely bright and true color vision when welding.

Technical Data

Shade levels
ShadeTronic inactive: shade level 2,0
active, manual: shade levels 7-12
ShadeTronic 4<12M with individual calibration option ± 2.

Energy supply
solar cells, Li polymer battery pack, chargeable via Micro-USB

Battery life range
300 to 500 charging cycles

Sensoric
Five sensors

Sensitivity
continuously, new with “Super High” sensitivity

Switching time
light to dark:
0,090 ms at 23°C
0,070 ms at 55°C
dark to light:
0,1 s to 2,0 s (with FadeTronic)

Field of vision
2.3 to 6.3 times bigger than a 100 x 50 mm standard ADF

Classification EN379
1/1/1/2

Shape stability
Mask: up to 220 °C
Front cover lens: up to 137 °C

Eye protection
UV/IR protection: maximum protection at all shade levels

Operating temperature
-10°C to + 55°C / 14°F to 131°F

Storage temperature
-20°C to + 70°C / -4°F to 158°F

Weight
640 g

Standards
CE, UKCA, ANSI, EAC, AS/NZS, compliant with CSA Z94.3
Compliant with pr ISO 16321 standard „WIG+“ („low amp Tig“)

Scope of delivery
Welding helmet, optrel IsoFit® headgear, manual, bag, Micro USB cable, front cover lens, warranty card

Warranty
from date of purchase: 2 years for manufacturing and material defects, 6 months for battery

Warranty extension
1 year additional (battery excluded) for online product registration within the first 6 months (from date of purchase) on optrel.com/register

The optrel helix CLT is available with integrated IsoFit® headgear and with a hardHat according to EN397 industry standard.
